How to Use Proxies in Java (HttpClient, OkHttp, Apache HttpClient)

Java still powers a huge amount of production infrastructure: APIs, crawlers, test harnesses, and internal tools. Many of these workloads need proxies to manage IP reputation, reach region-locked content, or keep sensitive infrastructure hidden behind an extra network layer.

Using proxies in Java lets you:

• Distribute requests across multiple IPs
• Respect rate limits and avoid bans
• Test applications from different regions and networks
• Separate internal infrastructure from public-facing traffic

This guide walks through proxy integration in modern Java using three major HTTP clients:

• java.net.http.HttpClient (Java 11+)
• OkHttp
• Apache HttpClient

You’ll see how to configure HTTP and HTTPS proxies, add authentication, handle timeouts and connection pools, rotate IPs safely, and test that everything works as expected.

---

Core concepts: proxies in Java

Before we dive into code, it helps to name the main moving parts.

• Proxy host / port
  The server and port your Java app connects to instead of going directly to the destination (for example, proxy.example.com:8080).

• HTTP vs SOCKS

  • HTTP/HTTPS proxies are most common for web and API traffic.
  • SOCKS4/5 proxies operate at a lower level and can carry many kinds of protocols.

• Authentication

  • IP allowlisting: your server IP is allowed to connect without credentials.
  • Username/password: credentials embedded in proxy URL or headers.

• Static vs rotating

  • Static proxies keep the same egress IP for long sessions.
  • Rotating proxies change IP per request or per session (via a gateway).

Most proxy providers document whether you should use HTTP or SOCKS, how to authenticate, and whether your connection goes through a static or rotating pool.

---

Why use proxies in Java applications

Typical Java use cases that benefit from proxies:

• Web scraping and data collection for analytics or price monitoring
• SEO and SERP monitoring from multiple regions and devices
• Ad verification across different geos and ISPs
• Localization testing of web apps and APIs
• Security and privacy for internal tools that access public sites

At scale, proxies also help you:

• Spread traffic across many IPs
• Respect target site limits while keeping throughput high
• Separate traffic between clients, regions, or business units

For these workloads, dedicated datacenter proxies are often a good fit: predictable, fast, and easier to integrate into Java HTTP clients.

---

Using proxies with Java 11+ HttpClient

The modern java.net.http.HttpClient (Java 11 and newer) has built-in proxy support.

Basic HTTP proxy

import java.net.*;
import java.net.http.*;

public class HttpClientProxyExample {
    public static void main(String[] args) throws Exception {
        ProxySelector proxySelector = ProxySelector.of(
                new InetSocketAddress("proxy.example.com", 8080)
        );

        HttpClient client = HttpClient.newBuilder()
                .proxy(proxySelector)
                .build();

        HttpRequest request = HttpRequest.newBuilder()
                .uri(URI.create("https://httpbin.org/ip"))
                .GET()
                .build();

        HttpResponse<String> response = client.send(request, HttpResponse.BodyHandlers.ofString());
        System.out.println(response.body());
    }
}

If your provider uses IP allowlisting, this is often enough: no explicit credentials, just the proxy host and port.

Proxy authentication (basic auth)

HttpClient does not have a direct setProxyCredentials method. Instead, you typically:

1. Embed credentials in the proxy URL (for some providers), or
2. Add an Authorization header (when the proxy expects basic auth), or
3. Use a custom Authenticator.

Example with basic proxy authentication using an Authenticator:

import java.net.*;
import java.net.http.*;
import java.util.Base64;

public class HttpClientProxyAuthExample {
    public static void main(String[] args) throws Exception {
        String proxyHost = "proxy.example.com";
        int proxyPort = 8080;
        String username = "user";
        String password = "pass";

        ProxySelector proxySelector = ProxySelector.of(new InetSocketAddress(proxyHost, proxyPort));

        Authenticator authenticator = new Authenticator() {
            @Override
            protected PasswordAuthentication getPasswordAuthentication() {
                if (getRequestorType() == RequestorType.PROXY &&
                    getRequestingHost().equalsIgnoreCase(proxyHost) &&
                    getRequestingPort() == proxyPort) {
                    return new PasswordAuthentication(
                            username,
                            password.toCharArray()
                    );
                }
                return null;
            }
        };

        HttpClient client = HttpClient.newBuilder()
                .proxy(proxySelector)
                .authenticator(authenticator)
                .build();

        HttpRequest request = HttpRequest.newBuilder()
                .uri(URI.create("https://httpbin.org/ip"))
                .GET()
                .build();

        HttpResponse<String> response = client.send(request, HttpResponse.BodyHandlers.ofString());
        System.out.println(response.body());
    }
}

Timeouts and connection settings

For production workloads, always configure timeouts and, if needed, redirects:

HttpClient client = HttpClient.newBuilder()
        .proxy(proxySelector)
        .connectTimeout(java.time.Duration.ofSeconds(10))
        .followRedirects(HttpClient.Redirect.NORMAL)
        .build();

You can also use HttpRequest.Builder#timeout for per-request timeouts:

HttpRequest request = HttpRequest.newBuilder()
        .uri(URI.create("https://httpbin.org/ip"))
        .timeout(java.time.Duration.ofSeconds(15))
        .GET()
        .build();

---

Using proxies with OkHttp

OkHttp is widely used in modern Java and Android apps for HTTP traffic.

Basic HTTP proxy

import okhttp3.*;

import java.net.InetSocketAddress;
import java.net.Proxy;

public class OkHttpProxyExample {
    public static void main(String[] args) throws Exception {
        Proxy proxy = new Proxy(
                Proxy.Type.HTTP,
                new InetSocketAddress("proxy.example.com", 8080)
        );

        OkHttpClient client = new OkHttpClient.Builder()
                .proxy(proxy)
                .build();

        Request request = new Request.Builder()
                .url("https://httpbin.org/ip")
                .build();

        try (Response response = client.newCall(request).execute()) {
            System.out.println(response.body().string());
        }
    }
}

Proxy authentication with OkHttp

Use an Authenticator to handle 407 Proxy Authentication Required responses:

import okhttp3.*;

public class OkHttpProxyAuthExample {
    public static void main(String[] args) throws Exception {
        String username = "user";
        String password = "pass";
        String creds = Credentials.basic(username, password);

        Proxy proxy = new Proxy(
                Proxy.Type.HTTP,
                new java.net.InetSocketAddress("proxy.example.com", 8080)
        );

        OkHttpClient client = new OkHttpClient.Builder()
                .proxy(proxy)
                .proxyAuthenticator((route, response) -> {
                    if (response.request().header("Proxy-Authorization") != null) {
                        return null; // Give up, already tried
                    }
                    return response.request().newBuilder()
                            .header("Proxy-Authorization", creds)
                            .build();
                })
                .build();

        Request request = new Request.Builder()
                .url("https://httpbin.org/ip")
                .build();

        try (Response response = client.newCall(request).execute()) {
            System.out.println(response.body().string());
        }
    }
}

Timeouts and connection pooling

OkHttp has sensible defaults but you should tune timeouts and connection pool behavior for scraping and high concurrency:

OkHttpClient client = new OkHttpClient.Builder()
        .proxy(proxy)
        .connectTimeout(java.time.Duration.ofSeconds(10))
        .readTimeout(java.time.Duration.ofSeconds(20))
        .writeTimeout(java.time.Duration.ofSeconds(20))
        .build();

Connection pooling is handled automatically. Reuse one OkHttpClient per proxy configuration instead of creating a new client per request.

---

Using proxies with Apache HttpClient

Apache HttpClient is still common in many enterprise stacks and older services.

Below are examples using HttpClient 5.x, but the concepts are similar in 4.x.

Basic HTTP proxy

import org.apache.hc.client5.http.classic.methods.HttpGet;
import org.apache.hc.client5.http.classic.CloseableHttpClient;
import org.apache.hc.client5.http.impl.classic.CloseableHttpResponse;
import org.apache.hc.client5.http.impl.classic.HttpClients;
import org.apache.hc.client5.http.impl.routing.DefaultProxyRoutePlanner;
import org.apache.hc.core5.http.HttpHost;

public class ApacheHttpClientProxyExample {
    public static void main(String[] args) throws Exception {
        HttpHost proxy = new HttpHost("proxy.example.com", 8080);

        DefaultProxyRoutePlanner routePlanner = new DefaultProxyRoutePlanner(proxy);

        try (CloseableHttpClient client = HttpClients.custom()
                .setRoutePlanner(routePlanner)
                .build()) {

            HttpGet get = new HttpGet("https://httpbin.org/ip");

            try (CloseableHttpResponse response = client.execute(get)) {
                System.out.println(response.getCode());
                System.out.println(new String(response.getEntity().getContent().readAllBytes()));
            }
        }
    }
}

Proxy authentication

Use credentials providers and auth scopes:

import org.apache.hc.client5.http.auth.AuthScope;
import org.apache.hc.client5.http.auth.UsernamePasswordCredentials;
import org.apache.hc.client5.http.impl.auth.BasicCredentialsProvider;

public class ApacheHttpClientProxyAuthExample {
    public static void main(String[] args) throws Exception {
        HttpHost proxy = new HttpHost("proxy.example.com", 8080);

        BasicCredentialsProvider credsProvider = new BasicCredentialsProvider();
        credsProvider.setCredentials(
                new AuthScope(proxy),
                new UsernamePasswordCredentials("user", "pass".toCharArray())
        );

        DefaultProxyRoutePlanner routePlanner = new DefaultProxyRoutePlanner(proxy);

        try (CloseableHttpClient client = HttpClients.custom()
                .setRoutePlanner(routePlanner)
                .setDefaultCredentialsProvider(credsProvider)
                .build()) {

            HttpGet get = new HttpGet("https://httpbin.org/ip");
            try (CloseableHttpResponse response = client.execute(get)) {
                System.out.println(response.getCode());
                System.out.println(new String(response.getEntity().getContent().readAllBytes()));
            }
        }
    }
}

Timeouts and connection management

You can configure timeouts on the client or per request:

import org.apache.hc.client5.http.config.RequestConfig;

RequestConfig requestConfig = RequestConfig.custom()
        .setConnectTimeout(10_000)
        .setResponseTimeout(20_000)
        .build();

try (CloseableHttpClient client = HttpClients.custom()
        .setRoutePlanner(routePlanner)
        .setDefaultRequestConfig(requestConfig)
        .build()) {
    // ...
}

Apache HttpClient also has rich connection pool controls; for high volume workloads, tune max total connections and per-route limits.

---

Implementing proxy rotation and pools

For heavier scraping or monitoring workloads, you rarely rely on a single proxy IP. Instead, you either:

• Use a rotating gateway from your provider, or
• Rotate through a list of proxy endpoints yourself.

Simple rotation pattern with OkHttp

import okhttp3.*;

import java.net.InetSocketAddress;
import java.net.Proxy;
import java.util.List;
import java.util.Random;

public class OkHttpProxyPool {
    private static final List<Proxy> PROXIES = List.of(
            new Proxy(Proxy.Type.HTTP, new InetSocketAddress("proxy1.example.com", 8080)),
            new Proxy(Proxy.Type.HTTP, new InetSocketAddress("proxy2.example.com", 8080)),
            new Proxy(Proxy.Type.HTTP, new InetSocketAddress("proxy3.example.com", 8080))
    );
    private static final Random RNG = new Random();

    public static OkHttpClient clientWithRandomProxy() {
        Proxy proxy = PROXIES.get(RNG.nextInt(PROXIES.size()));
        return new OkHttpClient.Builder()
                .proxy(proxy)
                .build();
    }

    public static void main(String[] args) throws Exception {
        OkHttpClient client = clientWithRandomProxy();

        Request request = new Request.Builder()
                .url("https://httpbin.org/ip")
                .build();

        try (Response response = client.newCall(request).execute()) {
            System.out.println(response.body().string());
        }
    }
}

In a real system you would usually:

• Reuse clients instead of creating one per request
• Attach metrics (success rate, latency) per proxy
• Remove or deprioritize proxies that start failing frequently

If your provider offers a rotating gateway, your Java code may only need a single proxy configuration; the rotation happens on the provider side.

---

Testing and validating your proxy setup

Always test proxies before plugging them into a production crawler or automation task.

Basic connectivity check

Use any client to call an IP echo endpoint such as https://httpbin.org/ip or an equivalent:

HttpClient client = HttpClient.newBuilder()
        .proxy(ProxySelector.of(new InetSocketAddress("proxy.example.com", 8080)))
        .build();

HttpRequest request = HttpRequest.newBuilder()
        .uri(URI.create("https://httpbin.org/ip"))
        .GET()
        .build();

HttpResponse<String> response = client.send(request, HttpResponse.BodyHandlers.ofString());
System.out.println(response.body());

If the JSON output shows a different IP than your own server, the proxy is active.

What else to test

• Geolocation: confirm the IP is in the expected country or city.
• Latency: measure round-trip time; slow proxies will bottleneck your job.
• Block and CAPTCHA rates: test real target sites where allowed.
• Concurrency: ramp up request rate and watch for connection errors or throttling.

Logging response codes, latency, and exceptions per proxy makes it easy to spot noisy or failing IPs.

---

Common errors and how to fix them

Error / Symptom	Likely Cause	What to Check / Fix
407 Proxy Authentication Required	Missing or wrong credentials	Verify username/password, or IP allowlisting status
java.net.ConnectException: Connection refused	Wrong host/port, proxy offline	Check endpoint, network ACLs, and provider status
java.net.SocketTimeoutException	Dead proxy or slow network	Increase timeout slightly or switch proxy
Lots of 403/429 from target sites	IP reputation issues, aggressive concurrency	Slow down, rotate proxies, or use cleaner IP ranges
SSL / TLS handshake errors	HTTP proxy misuse, outdated TLS	Use HTTPS proxies, update JVM trust store if needed
Random hangs without response	No timeouts or connection leaks	Always set connect/read timeouts and close responses

In all three libraries, make sure responses and input streams are closed to avoid leaking connections.

---

Security, ethics, and compliance

Even for technical teams, proxy usage is not just an engineering problem. Always consider:

• Terms of service
  Confirm that your intended scraping, monitoring, or testing is allowed by the sites involved.

• Robots and rate limits
  Even when data is public, respect robots directives when applicable and avoid abusive request patterns.

• Data protection
  If you touch user data or personal information, ensure you have a lawful basis and appropriate safeguards.

• Internal policies
  Coordinate with security and legal teams so proxy usage does not conflict with company policies.

• Logging and auditing
  Keep sufficient logs for debugging and compliance, but avoid storing sensitive payloads longer than necessary.

---

Frequently asked questions about Java proxy integration

Do I need all three HTTP clients in one project?

No. Most applications standardize on one primary HTTP client. Choosing between HttpClient, OkHttp, and Apache HttpClient depends on your existing stack, feature needs, and team familiarity. Many modern services use the built-in HttpClient or OkHttp and only bring in Apache HttpClient for legacy reasons.

Should I use HTTP or SOCKS proxies in Java?

For typical web scraping, API calls, and browser automation, HTTP/HTTPS proxies are sufficient and easier to configure. SOCKS proxies are more flexible at the TCP level but require additional libraries and are usually only needed when your provider specifically exposes SOCKS or you have non-HTTP protocols to tunnel.

How many proxies do I need for a Java scraping project?

It depends on concurrency, target strictness, and your error tolerance. A small batch job may work with a handful of IPs. Continuous high-volume crawlers often require dozens or hundreds so each IP only carries a modest amount of traffic. Start with a small pool, monitor block rates and latency, then scale based on real-world results.

Are free proxies safe to use with Java?

Free proxy lists are almost never appropriate for production Java workloads. They are usually slow, unstable, and controlled by unknown operators who may inspect or modify traffic. For serious automation and data collection, rely on reputable paid providers with clear documentation, support, and clean datacenter ranges.

How can I keep my Java proxy integration maintainable?

Abstract proxy configuration behind a small internal API: a factory for HTTP clients, a configuration object for hosts and credentials, and a simple rotation strategy. This keeps proxied and non-proxied calls consistent, makes it easy to swap providers, and centralizes logging, metrics, and error handling.

---

Conclusion: making proxies a first-class part of your Java stack

Proxies are no longer a niche concern reserved for custom scrapers. They are a core part of how modern Java systems access the web—whether you are building analytics tools, SEO monitoring, QA harnesses, or internal research pipelines.

By understanding how to configure proxies in HttpClient, OkHttp, and Apache HttpClient, and by layering in timeouts, connection pooling, rotation, and testing, you can build Java services that are both resilient and respectful of the sites they touch.

Teams that standardize on clean, dedicated datacenter proxies and good Java integration patterns find it much easier to scale workloads, troubleshoot issues, and stay compliant. When you design or upgrade a proxy layer for your Java services, treating proxies as a first-class part of the architecture helps your code focus on data and business logic rather than network headaches.
